DNGA150608 Coated CBN Carbide Turning Insert PCBN Cutting Insert for hardened steel
ManaNova is a concept that stands in the view of end-users, we strictly choose PCD and PCBN materials
to provide the universal cutting effect.
The key feature of ManaNova is Easy choice and Fast delivery.
"Easy choice": It is easy to choose according to the comparison table and application.
"Fast delivery": All the types of ManaNova PCD Inserts in the catalog are available in stock.
We will provide fast and efficientservice for domestic and foreign customers to meet their demand for
standardized and universalized tools.
Specification:
| Material | ISO H | ISO K | ISO S |
| PCBN Grade | MHN10C | MHN20C | MNH30C | MKN10 | MKN20 | MSN10 | MSN20 |
| Smooth | Moderate | Toughness | Cast Iron | Ductile Iron | Powder Metallurgy | Powder Metallurgy |
| Vc | 180(150~250)
m/min | 100(50~150)
m/min | 80(30~120)
m/min | 600(300~800)
m/min | 300(150~450)
m/min | 300(200~500)
m/min | 500(300~800)
m/min |
| fn | 0.1(0.03~0.2)
mm/r | 0.1(0.03~0.2)
mm/r | 0.1(0.03~0.2)
mm/r | 0.1(0.03~0.3)
mm/r | 0.1(0.03~0.3)
mm/r | 0.1(0.03~0.3)
mm/r | 0.1(0.03~0.3)
mm/r |
| % | 45~55 | 60~70 | 85~95 | 85~95 | 60~70 | 60~70 | 85~95 |
| Grain size | 1~2 um | 1~2 um | 2~3um | 2~3 um | 1~2 um | 1~2 um | 2~3 um |
| Bond | TiC | TiN | Co/W | Co/W | TiCN | TiCN | Co/W |
| DNGA | Shape | Dimensions |
| ANSI Code | ISO Code | Tips | IC
mm | S
mm | R
mm | Φd
mm | LE
mm |
All
Stocked | DNGA 431 | DNGA 150404 | 2N | 12.7 | 4.76 | 0.4 | 5.16 | 2.2 |
| DNGA 432 | DNGA 150408 | 2N | 12.7 | 4.76 | 0.8 | 5.16 | 2.2 |
| DNGA 433 | DNGA 150412 | 2N | 12.7 | 4.76 | 1.2 | 5.16 | 2.2 |
| |
| DNGA 441 | DNGA 150604 | 2N | 12.7 | 6.35 | 0.4 | 5.16 | 2.2 |
| DNGA 442 | DNGA 150608 | 2N | 12.7 | 6.35 | 0.8 | 5.16 | 2.2
|
Application:
| MHN10C | Applied to the continuous cutting of hardened steel |
| MHN20C | Applied to medium interrupted cutting of hardened steel |
| MHN30C | Applied to the heavy interrupted cutting of hardened steel |
| MKN10 | Applied to the cutting of gray cast iron |
| MKN20 | Applied to the cutting of ductile iron |
| MSN10 | Applied to the cutting of powder metallurgy |
| MSN20 | Applied to the cutting of powder metallurgy |
Worldia ManaNova series covers 7 high-quality CBN grades for the processing of hardened steel,
cast iron, and powder metallurgy, the available grades are MHN10C, MHN20C, MHN30C,
MKN10, MKN20, MSN10, and MSN20.
Service:
· Online store service
· Local distributor support
· Technical support
Main products:
PCBN insert is suitable for machining hardened steel, gray cast iron, ductile iron, and powder.
PCD insert (MND10 material ) is suitable for rough and finish machining of aluminum alloy and other non-metal materials.
